Product features
The GNSS Patch Module is designed to work in single-frequency or multi-frequency sharing mode
Covers the full frequency of GPS/GLONASS/BDS/GALILEO four systems
Customized design,can match different styles of antennas according to the dimensions of the client's models
High gain
High temperature stability
Low noise
Excellent pattern
High precision
Frequency
| Satellite communication field | ||||||||||||
| Center Frequency(MHz) | GPS L1 | GPS L2 | GPS L5 | BD2 B1 | BD2 B2 | BD2 B3 | GLONASS L1 | GLONASS L2 | GALILEO E1 | GALILEO E5a | GALILEO E5b | GALILEO E6 |
| 1575 | ● | ● | ||||||||||
| 1568 | ● | ● | ||||||||||
| 1590 | ● | ● | ||||||||||
| 1561 | ● | |||||||||||
| 1268 | ● | ● | ||||||||||
| 1602 | ● | |||||||||||
| 1227 | ● | |||||||||||
| 1176 | ● | ● | ||||||||||
| 1207 | ● | |||||||||||
| 1246 | ● | |||||||||||
| 1278 | ● | |||||||||||
